Premium Class Network CD Receiver
The Network CD Receiver SA-C600 brings you a wealth of music content with a single device everything from records, CDs, and radio to music streaming and more besides with a luxurious audio environment courtesy of Technics’ superior sound engineering.
Full Digital Amp, JENO Engine (Jitter Elimination and Noise-shaping Optimisation)
The SA-C600 uses a fully digital amplifier incorporating Technics’ renowned digital audio technology. Its digital transmission system processes signal fully digitally in all stages from input to output. Compared to analogue transmission, this system is less susceptible to signal degradation caused by external noise, ensuring more precise signal transmission. Accurate signal processing not only delivers high-resolution digital audio but also maintains the soft texture inherent in analogue recordings.
Twin Power Supply Circuit System
The design of the power supply is extremely critical in audio systems containing CD players amplifiers, digital circuits and other such components. To eliminate any adverse effects on the amplifier, the SA-C600 is equipped with a dedicated power supply for the amplifier circuits that is independent from all other circuits, supplying power to the two independent transformers. The wiring connections between the two dedicated transformers and the amplifier circuits are also optimised for noise reduction.
Clean Powered Clock Generator
The power supply for the clock circuit of the JENO Engine utilises the same noise suppression circuit employed in Technics’ flagship turntable model, the SL-1000R, to improve noise reduction. It achieves superb sound image localisation and transparent spatial expression.
Built-in Phono Equaliser compatible with MM Cartridge
The built-in phono equaliser supports MM cartridges. The phono equaliser uses a dedicated power supply and is equipped with a power supply circuit that is different from the control circuit for improved noise reduction. The equaliser circuit also features a shielded construction to shut out the effects of external noise and allows for signal amplification without any loss of fidelity.
Space Tune™
The SA-C600 is equipped with a Space Tune function that enables the adjustment of sound to suit the environment and location of the unit so that anyone can enjoy superb music reproduction. By using the Technics Audio Centre* app for tablets and smartphones or by selecting one of the four pre-sets on the main unit - Free, Wall, Corner and Shelf. The user can achieve the most suitable sound reproduction for their specific acoustic environment. The L/R Custom feature allows users to enter separate settings for each individual speaker, adjusting for installation under different conditions and bringing out the best sound quality in any environment. * Available for iOS devices only.
Compatible with a variety of music sources
The SA-C600 supports a variety of music sources including CD, radio, phono input, optical digital input (including TVs), coaxial digital input, USB input, and more.
Enjoy high-quality sound wirelessly
The SA-C600 can playback high-resolution music wirelessly. It supports not only Bluetooth® and AirPlay 2, but also Spotify Connect®, TIDAL, Amazon Music, and more, and comes with Chromecast built-in™.
Compatible with MQA
The SA-C600 supports MQA and can playback MCA-CD and MQA files downloaded from music streaming services with outstanding sound quality.
Designed for Sophisticated Music Listening Experience
To ensure consistency of appearance, the design of the SA-C600 incorporates elements from Technics turntables such as colour, texture and dimensions, improving the aesthetics of the system. The aluminium top panel sports a built-in CD player with a manually operated lid for ease of use and functional beauty.
Specifications:
Output Power
|
60 W + 60 W (1kHz, T.H.D. 1.0 %, 4Ω, 20kHz LPF)
|
Load Impedance
|
Ω-16Ω
|
Frequency Response
|
PHONO (MM)
LINE
DIGITAL
|
20Hz - 20kHz ( RIAA DEVIATION ±1dB, 8Ω )
20Hz - 80kHz ( -3dB, 8Ω )
20Hz - 90kHz ( -3dB, 8Ω )
|
|
Input Sensitivity / Input Impedance
|
PHONO (MM)
LINE
|
2.5 mV / 47 kΩ
200 mV / 22 kΩ
|
|
Analogue Input Terminal
|
LINE x 1 PHONO (MM) x1
|
Digital Input Terminal
|
Optical digital x1 Coaxial digital x1 USB-A x1 USB-B x1 (PC)
|
Analogue Output Terminal
|
Sub Woofer x1
|
Headphone Output
|
Yes, Stereo Φ3.5 mm
|
Disc Compatibility
|
Audio CD, CD-R/CD-RW (CD-DA, Discs recorded and finalised on recording devices)
|
USB-A
|
|
iPod/iPhone/iPad
|
No
|
Support Codec
|
WAV
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
FLAC
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
DSD
|
Yes (2.8 MHz, 5.6 MHz, 11.2 MHz)
|
AIFF
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
ALAC
|
Yes(32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
AAC
|
Yes (32, 44.1, 48, 88.2, 96 kHz/16-320kbps)
|
MP3
|
Yes (32, 44.1, 48 kHz / 16-320 kbps)
|
|
PC(USB-B)
|
|
USB Audio Class Specification
|
USB 2.0 high-speed USB Audio Class 2.0, Asynchronous mode
|
Support Codec
|
LPCM Yes (32, 44.1, 48, 88.2, 96, 176.4, 192 kHz / 16, 24 bit) DSD Yes (2.8 MHz, 5.6 MHz)
|
DSD control mode
|
ASIO Native mode, DoP mode
|
MQA Decorder
|
Yes
|
|
WAV
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
FLAC
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
DSD
|
Yes (2.8 MHz, 5.6 MHz, 11.2 MHz)
|
AIFF
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
ALAC
|
Yes(32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
AAC
|
Yes (32, 44.1, 48, 88.2, 96 kHz/16-320kbps)
|
P3
|
Yes (32, 44.1, 48 kHz / 16-320 kbps)
|
|
Ethernet Interface
|
LAN (100 Base-TX/10 Base-T)
|
Wi-Fi
|
IEEE 802.11 a/b/g/n/ac 2.4 GHz / 5 GHz Band
|
Chromecast built-in
|
Yes
|
AirPlay 2
|
Yes
|
Bluetooth® (Support codec)
|
Yes (AAC, SBC)
|
Tuner
|
DAB/DAB+/FM
|
Power Supply
|
AC 220 V - 240 V, 50/60 Hz
|
Power Consumption
|
46W
|
Dimensions (W x H x D)
|
40 mm × 94 mm × 341 mm
|
Weight
|
Approx. 4.8 kg
|
Accessories
|
AC Cord, DAB Indoor Antenna, Remote Control, Batteries for Remote, Owner's Manual
|
